Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 152
Fig. 37. Diagram of Armature Winding 128 ELECTRIC RAILWAYS 33 … the three coils in one slot are treated as if they occupied sep-arate slots in the diagram. In Fig. 37 the path of the winding can befollowed thus: A coil is in the top of slot 1 andin the bottom of slot 4; another in the top of 2and bottom of 5, etc. One terminal of the firstcoil goes to…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
