Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 154
rted by hollow extensions from the main frame and firmlyclamped between these and cast-steel axle caps above. The bearing housings provide not only support for the bushings,but also form chambers for the lubricant. The section of one ofthe bearings of this motor is shown in Fig. 4L A large… … Fig. 41. Cross-Section of Bearing Housing the oil-soaked waste to come into contact with the shaft which isthus well lubricated. Surplus oil passes into the chamber to theright and spills into the roadway. An important feature of the lubrication is the oil ring whichis carried on each end of the…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
