Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 262

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 262
Fig. 123. Section of Pneumatic Sander The fuse may be of any of the types in common use, either open orenclosed. Lightning arresters are used on all cars taking current from … Fig. 124. Typical Automatic Circuit Breaker overhead lines. The lightning arrester is connected to the maincircuit as it comes from the trolley base, before it reaches any of theother electrical devices on the car, so that it may afford them pro- 227 132 ELECTRIC RAILWAYS tection. One terminal of…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
