the air and the consequentshort-circuit of the line. Onthe top of the insulator is agroove in which the conductorlies and below is a flange towhich some kind of a bindingor clamping device is attached. Typical high-tension in-sulators are shown in Figs. 176and 177. The form of insula-tor described… … Fig. 178. Modern High-Tension ,Suspension Insulators 297 200 ELECTRIC RAILWAYS —ma/ iron eye developed in which the conductor hangs from the insulator and theinsulator from the cross-arm. Fig. 178 shows a very modern high-tension tower equipped withsuspension insulators. Thewires, which are not…
