STRAIGHT A/R VALyE AIR GAUGE Fig. 244. Sectional Elevation and Plan of Typical Electric Locomotive 354 ELECTRIC RAILWAYS 257 elevation and partial section of this locomotive. Fig. 246 is froma photograph showing its actual appearance. The New York Central locomotive is driven bv four direct- … current, gearless, bipolar motors. The mounting of the motors isclearly shown in Fig. 245. The armatures are solidly mounted onthe driving axles, while the pole pieces form a part of the spring- 355
