Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 131

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 131
circuit breakers always used should 113 16 SWITCHBOARDS be mounted at the top of the panels, where any arc blown up fromthe contacts when the breaker opens will do no harm. Instrumentsare logically placed just below the circuit breakers because thatlocation brings them at about the right height to… … Fig. 11. Direct-Current Switchboard with Generator and Feeder PanelsCourtesy of General Electric Company bases. Fig. 11 shows a direct-current switchboard, consisting ofgenerator panels and feeder panels, a voltmeter being mounted ona bracket at one end. The equipment is simply and…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
