Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 133
Fig. 13. Two-Wire Lighting Boardwith Separate Feeder Circuits I 1 D.c Cien^RA TOR Fig. 14. Wiring Diagram forFig. 13 … Fig. 15. Two-Wire lighting Board with Three-Pole Switch for Compound Wound Generators Operating in ParallelCourtesy of General Electric Company 116 SWITCHBOARDS 19 both the generator and feeder equipments can be built where theplant contains only one generator and up to about six feeders.After…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
