i … i 1 Circuit breaker 1 Ammeter 1 Single-pole lever switch 1 2-point potential receptacle, for reading the trolley voltage before connecting in the feeder The equipment may be modified at times, asfor instance, putting two circuits on one paneland having a common circuit breaker for thetwo, or a…
