tsthe leads to the sparking coilterminals. It will readily beseen from the diagram that bythrowing the switches in oppo-site directions, one battery willbe charging while the other oneis discharging to the engine,thus giving a constant source ofsupply, at the same time insuring that the spare… … Fig. 61. Small Ignition Battery with Double CircuitCourtesy of Electric Storage Battery Company T
