the switches when the current in C is cut off.The wiring diagram for a single-speed full magnet controller is givenin Fig. 134. Fig. 135 shows the method used by another manu-facturer to accomplish the same purpose. Where a variablespeed is desired, a controller, Fig. 136, similar to Fig. 133,… … Kite. l6o. TuU Automatic Skip I^ist, Controller for Alternating CiirRiuCourtesy of Otis Elevator Company the speed. This solenoid is energized by the mo^cments of the carswitch and is entirely under the control of the operator. The wiringdiagram for a two-speed full magnet controller is given in…
