Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 375
dvantage of this outfit lies in its lowfirst cost but the extremely low efficiency of such a system preventsits use in industrial establishments. The diagram of connections,Fig. 61, shows the relation of the various parts of the circuit and theswitches for cutting the resistance grids into and out… … <^^IN=^ C/IRBON + Fig. 61. Wiring Diagram Showing Principal Features of the Indianapolis TrackWelding System breaker should not open quickly on overload. The maximum cur-rent obtainable, however, is limited by the amount of resistance incircuit, so burned work is not liable to result excepting…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
