i-automatic keys sometimesresults in a very jerky style of sending, because the automaticvibrator, which makes the dots, spaces them at certain regular timeintervals, and if the operator does not make the daslies of a corre-sponding length irregular signals will be made. 34 MODERN LAND AND… … Fig. 11. Standard Morse Local SounderCourtesy of Postal Telegraph-Cable Company louder and clearer sound. Fig. 11 illustrates a standard sounder foruse in connection with a relay. Such sounders have a resistance of4 or 5 ohms and are usually operated with a current of about a quar-ter of an ampere.…
