REPEATER. -i. Fig. 20. Wiring Diagram for Ghegan Automatic Repeater armaiure contacts on the other transmitter which repeats the mes-sage. A diagram of the circuit connections is shown in Fig. 20. Milliken Repeater. The IMilhken repeater set includes repeatertransmitters of the type shown in Fig.… … Fig. 21. Milliken Repeater Relay relays, and Fig. 22 is a diagram of the circuit connections of therepeater set. The tension of the spring on the auxiliary magnet armature isadjusted so as not only to pull back the auxiliary armature but asoto hold normally the armature of the main relay magnet in…
