^C … ^m ^m Fig. 118. Joist Supported by Brick Wall. Fig.119. Use of Anchor. anchor (as shown in Fig. 119), of which there are several kinds onthe market. Fio-. 120 shows the result when a beam which iscut off square on the end, falls out of the wall. There must always be left around the end of a beam…
