Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 110
r. 76 CAKPENTKY Unsupported Corners. An interesting place in a floor fram-ing plan is where we have a corner without any support beneathit, as at the corner a in Fig. 123. This corner must be supportedfrom the three points ?>, c, and d, and the figure shows how this isaccomplished. A piece of… … s z o OS ooa <s < u QU en X O ao to -7 ■ ^ -r OSOb O <HHOO o:u s in § S S p. CARPENTRY PART II. THE ROOF. In Part I we saw that the subject of framing could be con-sidered under three distinct headinors; the framing of the wall,the framing of the floor, and the framincr of the roof. So far…
Architecture · Building · Carpentry
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
