Ficr. 26 A. Modified Butt Joints. Fig. 26 B. through the tenon at c, and another hole in the mortised piece atd. These holes are so placed that when the pieces are joinedtogether, a wooden pin may be driven through both holes, thuspreventing the tenon from being withdrawn from the mortise.This pin…
