Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 203
Fig. 208. Studs Beveled to Fit UnderSide of Rafter Fig. 209. Cutting Studs for PartitionRunning Parallel to Rafter stick, the distance K R is just 4 inches or one-third of the run of therafter, and consequently the distance R N is just 3 inches, or one third of the rise of the rafter. In the case…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
