Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 216
Fig. 223. Fitting Girders to Steel Beams by Meansof Angles 170 … d Pk S P »-> w -a m 4 g^ CXi H CARPENTRY 159 commonly used, especially in warehouses, stables, and other build-ings where the appearance is not an important consideration. In Fig. 224 is shown a beam which is trussed by the first methodwith compression pieces A above the beam. All the parts are…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
