he plane, if necessary, so as to bringit parallel with the edge of the bottom of the plane, where it passes throughthe slot. No. 11 is the handle, which is fastened to the bottom of the plane bythe handle screw, No. 15, and by the handle bolt and nut, No. 13. No. 12 is the knob, fastened to the… … Fig. 31. Details of Parts of Smooth Plane Nails. In general, nails are of two kinds, namely, cut nailsand wire nails, the difference between the two kinds being in thematerial and the method of manufacture. Cut Nails. The cut nails, also called plate nails, are stampedout of a flat iron plate, in…
