FOR THE CHICAGO & NORTHWESTERN RAILWAY COMPANY, CHICAGO, ILL., JACKSON BOULEVARD SIDE Frost & Granger, Architects; E. C. & R. M. Shankland. Engineers.This Illustration shows the Modern Steel Column ami the Greek Doric Column—the StructuralColumn and the Applied Classic Column—Side by… … OFFICE BUILDING FOR CHICAGO & NORTHWESTERN RAILWAY COMPANY, CHICAGO Details of wind-bracing construction in basement. Note connection of beams to girders, also girder connection to column. Note that all connections are riveted. INSERT FOLDOUT HERE STEEL CONSTRUCTION 179 Section cf /foof Co/umn…
