study and provisionalframing plans, to use tracing paper, which can be placed over thearchitects plans, and thus show the position of all partitions, ducts,etc. 59 5-2 STEEL CONSTKITCTION Position of Columns. The first step is the location ofcolumns. These should always come in partitions, unless… … Typical Floor Plan Fig. 42. transverse to the longest dimension of the building. The girderspans should also be shorter than the beam spans, as otherwiseexcessive depth of girders will be required. In general, therefore,the shortest spacing of columns should be in the direction of thelongest…
