er section ofcolumn, and also, because of the light load, a column of four anglesand a web was desirable. Tliis upper column, therefore, sets downinside of the channel column and is riveted to it as shown by thedetails. Fig. 187 shows the connection of the girders in the wings tothe columns ; the… … o ® o ^ s a .9 c« o 1! fa ?, ?^ o STEEL CONSTRUCTION, PART III. DEFINITIONS AND ABBREVIATIONS. In all structural steel detailing certain abbreviations are so com-monly used that it is essential at the outset for the student to befamiliar with them. The more common are given below: PL = Plate C —…
