5. 12, Given a 15-in,, 42-ib. beam framed between the webs oftwo columns, 20 ft. 8 in. center to center on a line perpendicular to 259 250 STEEL CONSTRUCTION the axis of the webs, and the center of one column is 1 ft. 9 in. offfrom the other in the direction of the webs. The webs of the cohimnsare… … JJ S 6 a B ►J o o .2M a p, STEEL CONSTRUCTION PART IV RIVETED GIRDERS Functions of Flanges and Web. Riveted girders are made up oftwo general parts (a)—the top and bottom members—which aretermed, respectively, the top and bottom flanges-, and one or more ver-tical plates (b), called the iveb-plate,…
