STRUCTURAL DRAFTING 85 various angles are drawn in, tlie first ri\et is set back 11, ]\, or I2inches as the sizes of the angle and of the rivet allow, and the otherspacing is so arranged as to make the size and shape of the plateadvantageous and economical. The distance from the first rivetto the…
