drawing, true lengths appear oidy as 30° linesor as vertical lines. Edges or lines that in actual j)rojection areeither parallel to the ground line or perpendicular to V, are drawnin isometric as 30° lines, full length; and those that are actuallyvertical are made vertical in isometric, also full…
