Fig. 4. Shade Lines. i M A: i m ■h- m s •c- Fig. 5. .Tmiftions of Lines. the same holds good, as isshown in Fig. 5. In an elevation, theplanes toward the frontmay ))e drawn with darklines and tho.se farther back with lighter lines. Joint lines in masonryand the lighter lines of carving should be… … First Prize Design. National Maine Monument. H. Van Buren Magonigle, Architect. 10 ARCHITECTURAL DRAWING Sometimes lines of different colors, as red to indicate brick,blue for stone, yellow for wood, etc., are used on working drawingsto take the place of tinting. DEFINITIONS. Architectural drawing…
