Fig. 16. Nest of Saucers. Inking the Drawing. The lines should be drawn withground India ink, the ink being as black as possible without beingtoo thick to flow. Ornament should be inked in with lighter linesthan the vertical and horizontal lines. This accents the struc-tural lines. Very often the… … RENDBRING OF ROMAN IONIC CAPITAI.. Showing conventional shadows and reflected lights and shadows. Reproductd by permission of Columbia Universilv. 1 ARCHITECTURAL DRAWING 25 should vary with the scale of the drawing, the larger and bolderthe drawincr the wider the line. India ink evaporates very…
