wn the hat brim until thepoint coincides with it, turning on the heel carry the horizon levelto the direction desired. This will give a point at the level with theeye. Elevation Measurements. Total distances should be taken,and interior heights from floor to floor (with thickness of floors)should… … Fig. 33. Twelve-incli Single Jointed Kule and Level. taking dimensions to centers of windows or edges of stone or brickopenings. Measurements are given by some architects from frameto glass openings. Sketches or details should be made of typicalwindows, and variations from the type. Roof pitches…
