Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 342
PLATE C … PLATE D 56 ARCHITECTURAL DRAWING the plate mentioned before. Reflected shadows are to be put inand care should be taken to show the reflected lights in the shade. PLATE IV. This plate is to be drawn double the size of plate D, A mar-gin one and one-half inches is to be left as a white border…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
