Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 433
hs. The space betweenthe pilasters, occupied by the arches of the arcade, is determinedby the spacing of the triglyphs, four of which occur over thearches. These pilasters are repeated in the interior or the gallery,which is covered by a flat ceiling, supported by an entablaturewhose details are… … CHAPEL PLATE XXIX.(A reproduction at small size or Portfolio Plate XXIX.) k THE ROMAN ORDERS 57 from the faces of the corner j^iers. This combination is shown in dotted lines on the plan. The gallery arches are repeated on the blank wall which encloses the gallery. The exterior entablature is…
