tive of theupper edge, vertically under the intersection of HPP with thehorizontal projection of a visual ray drawn through the point g inthe diagram. The jjosition of Jc^ may be established in a sinnlarmanner. Vertical lines drawn through g^ and k^ respectively,will complete the perspective of the…
