section must be obtained on B O, and a set of sections d(welopedas follows: Divide one-half of 1 4 T in rear elevation into equalparts as shown from 1 to 4, from which draw horizontal linesintersecting the line B C as shown. From these intersectionslines are drawn at right angles to B C equal in… … 97 38 SHEET-METAL WORK and place it as shown by similar letters in Fig. 33. Now taketracings of the half sections in Fig. 32, as H E D C, C 1 B,P O S, and the (quarter x)lan N J M, and place them in Fig. 33 onsimilar lines on which they represent sections as shown respectivelyby H 9 8 C, 0 8 B, A 3…
