Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 145
a-b-c SLIGHT BENDS Fig. 56. Fig. 57. We assume that the amount of rise and i^rojection of the elboware not specified, excepting that the lines of axis will be at rightangles. Knowing the angle of the miter line, it becomes a matterof judgment upon the part of the pattern draftsman, what…
