e of an intersectionbetween pipes having different diam-eters in boiler work is shown in Fig.13B. ^Vhile the method of obtainingthe j)atterns is similar in principle toparallel line developments, a slightchange is required in obtaining theallowance in the stretchout for the thickness of the metal… … Fig. 1.33.
