Fig. 21.For the pattern proceed as follows: With 13 as center andradii equal to EF and BE, describe the arcs GH and IJ. Draw aline from G to B. (Starting from the point G lay off on the arc Gil,the stretchout of the semi-circle EAE, as shown by similar figureson GIL From II draw a line to B,… … FRONT AND REAR VIEWS OF RESIDENCE OF HENRY STEINBRENNER, BELLFLOWER AVENUE, CLEVELAND, OHIO Watterson & Schneider, Architects, Cleveland, Ohio. Brick Used ou Exterior is McCausland Brick. Made at Akron, Ohio. Roofs Covered with ■Imptriar Red Tile. TINSMITIIING 19 Funnel and Spout. In Fig. 22 is…
