ntersecting the back of the scoop as shown. From theseintersections at right angles to the center line, draw lines inter-secting the side of the boss at abvd. For the pattern proceed asshown in diagram w. AVith radius equal to fe in the side viewand/* in tc, as a center describe the arc aa. Draw a… … 80 TmSMITHING 23 draw radial lines to the center f. Now using f in to as a centerdescribe the arc //. In similar manner, using as X2<.^\\f(i\fh\fc\f(V and fe in side view, and f in vj as center, describe arcs inter-secting radial lines having similar letters as shown. A line tracedthrough points…
