Fig. 54. Exterior View of a Common Type of Radiator for Indirect-Steam Heating. be used for either steam or hot water, as there is a continuous passagedownward from the supply connection at the top to the return at thebottom. These sections or slabs are made up in stacks after the … Fig. 55. Interior Mechanism of Radiator Shown in Fig. 54. manner shown in Fig. 57, which represents an end view of severalsectidiis connected together with special nipples. • A very efficient form of indirect heater may be made up ofwrought-iron pipe joined together with branch tees and return…
