water underpressure takes the place of steam. A piston in the upper cvlindercompresses the air, which is stored in a reservoir provided for thepurpose, ^\h.en the pressure in the reservoir drops below a certain 199 190 HEATING AND VENTILATION point, the compressor is started automatically, and… … Fig. IfiT. Air-Compressor Operated by Wa-ter-Pressure, Automatically routi-olled.and Operating to Regulate Temperatureby Controlling Radiator Valves. Fig. 168. Thermostat Controlling Valveson Radiators, and Ojjerating through Ex-pansion or Contraction of Metal Stiip E. ture of the air in which it…
