Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 432
Floor of Double-Flat Building. (lucing a current in the local vent stack is doing its duty. Fig. 166shows the openings left for a battery of closets that are to be set on a 858 PLUMBING 135 tile floor. The uprights connect into a branch soil line below. Theillustration is given to show a system of… … Fig. 168. Plan of Complete Installation Shown in Part in Fig. 167. stack .system is made proportional; that is, the area of the stack atany point is an approximation to the aggregate area of all the ventbranches that have been connected into it up to that point. Thelocal vent stack is sometimes…
Architecture · Building · Carpentry
