Fig. 202. Open-Wall TrapPartly Cast. 370 PLUMBING 147 … Fig. 203, Common LeadDi-um or Pot Tiap. of brass, is shown in Fig. 202, the vent connection to wall being at A.This form of trap generally has a swivel-joint at B, which is below thewater line, so that the body may be swiveled to meet roughing-inopenings in any direction within two diam-eters of…
