Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 213
Fig. 223. Fitting Girders to Steel Beams by Meansof Angles 170 … CARPENTRY 159 commonly used, especially in warehouses, stables, and other build-ings where the appearance is not an important consideration. In Fig. 224 is shown a beam which is trussed by the first methodwith compression pieces A above the beam. All the parts are of
