Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 243
ome were carried downto meet this plane all the wayaround. In order to cover every partof the building, the dome mustbe large enough to include thecorners, and if made sufScientlylarge for this it must overhangthe side walls of the building, byan amount A E B on each side,if the framing is carried… … Fig. 256. Diagram Showing Relation ofDome Roof of Square Building 195 184 CARPENTRY
