Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 252
intersect, and to which thediagonal rib must conform. By continuing the line from the point 0 at right angles to itsformer direction and parallel to the wall line, we may obtain thepoint K, which is a plan of one point in the surface of the ellipticalvault. The elevation of this point also above… … STAIR HALL OF HOUSE IN URBANA, ILL.
Architecture · Building
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
