Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 69
Fig. 33. Diagram ShowingWrong Ground Layout … Fig. 34. Batter Board to Indicate Layout square and the tape measure. The accuracy of the right angle maybe checked by the use of the three-four-five rule. This rule isbased upon the fact that a triangle, whose three sides are, respectively,3, 4, and 5 feet long, is an exact right-angled triangle,…
Architecture · Building
