Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 80
Fig. 42. Form of Bridge orStraddle Joint Fig. 43. Anothor Form of Bridgeor Straddle Joint used wherever the pieces are perpendicular to each other. When,however, the pieces are inclined to each other, a modification of the 60 CARPENTRY 51 above joint known as the bridge or straddle joint is…
Architecture · Building
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
