Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 83
Fig. 47. Pinned Tenon-and-TuskJoint Fig. 48. Pegged. Tenon-and-TuskJoint as shown in Fig. 48, so as to pass clear through the mortised piece,and to fasten it with a peg B on the other side. The peg may be cutslightly tapering, as shown, so that when it is driven in place it willdraw the pieces…
Architecture · Building
