Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 266
haust of both cyl-inders. The ex-haust steam fromthe high-pressurecylinder becomesthe supply steam for the low-pressure cylinder.As the supply steam for the high-pressure cylinder Figure 122 … Figure 123 inters the steam chest at both ends, the only varia-tion from balance being area of steam at backend, an advantage in case valve or connection to 266 LOCOMOTIVE ENGINEERING the valve-rod should be broken, as it holds themtogether. Cases are reported where compound loco-motives of this…
