the Equipment. If it is tobe placed on the front end as shown in Fig. 212,measure the depth of the headlight case to be usedand add 18 inches to this measurement. Then havea baseboard made, using these measurements for thelength of board, and make the breadth the standardwidth for oil headlights.… … CO 1—I H « O HO INJECTORS STEAM GAUGES, ETC. 429 board. Place this iron ,!UV on the brackets withinabout two inches from the stack and mark for boltsthrough brackets. Put baseboard on the iron U so the back edgewill just clear the stack, and bolt to brace. Place theequipment on the board, with…
