vertical beam forms a constant warningsignal. Reaching to a great height, and on cloudynights striking the clouds, it can be seen for manymiles. In fact, upon the Big Four road it has beenseen for a distance of 21 miles, and on the Chicago,Milwaukee and St. Paul road it has been seen for adistance… … INJECTORS, STEAM GAUGES, ETC. 445 All that is necessary is to secure the bedplate at theproper place on the smoke arch by means of bracketsbolted thereon, the running of a three-quarter-inchlive steam pipe from the cab, and the passing of aone and one-quarter-inch exhaust pipe into the smokearch.…
