Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 842
PLAN VIEW SLIDE VALVE. … SLIDE VALVE SEAT. FIG. 350. GRADUATING VALVE, SLIDE VALVE, AND SLIDE-VALVESEAT. TYPE L TRIPLE VALVE ket; 23, Bolt and Nut for Cylinder Cap; 24, Bolt and Nutfor Check-Valve Case; 25, By-Pass Piston; 26, By-PassPiston Ring; 27, By-Pass-Valve; 28, By-Pass-Valve 786 LOCOMOTIVE ENGINEERING Seat; 29,…
Locomotives
